Ballistic Separator

Ballistic Separator

Alwazo Solution’s Ballistic separators(also known as Gravity separator/Bounce screening separator)  are engineered specifically for waste material sorting. These separators, aptly named for their high-load capacity, effectively segregate various types of waste. Comprising parallel agitating paddles and a high-speed oscillating deck, they efficiently separate a stream of waste passed through them.

Similar-shaped and sized waste products are sorted into two or three fractions. For instance, stones, Construction & Demolition (C&D) waste, glass, and metal substances are easily segregated from reusable materials like paper, plastic, cardboard, and other recyclables, including Refuse Derived Fuel (RDF). The remaining materials are separated from the mix.

These separators are equipped to handle fine particles, which can be sorted separately with optional variable screen openings. Not only are they durable and precise, but the Ballistic Separators from Alwazo Solutions also boast additional performance-enhancing features. Moreover, they are newly designed and tailored to meet each client’s specific requirements.


The number of paddles in ballistic separators determines the screening surface area and material flow processed by the separator.

4 Paddles: This is the smallest type, suitable for use in smaller plants or to enhance collection efficiency in combination with an air separator.

8 Paddles: An intermediate variant, which can include oversized paddles to increase the screening surface while maintaining the same number of paddles. This variant slightly increases the overall dimensions. It offers diverse functions, such as distinguishing between cardboard > A4 and differentiating between bottles (3D) and film (2D) in plastic waste.

12 Paddles: Specifically designed for waste sorting plants with high flow rates. Available with regular and oversized paddles, the latter creating a system with a 4300 mm internal working diameter and a screening surface of 24 m2.

16 Paddles: Among the world’s largest ballistic separators, with an internal diameter of nearly 6 meters and a screening area of 32 m2. Ideal for systems with increasing flow rates (sorting lines of 50+ t/h).

1. Fast production
2. Less wear & tear
3. Separated 3 Fractions of Material
4. Easy to maintain
5. Low power consumption
6. Low manpower requirement
7. Long-lasting bearing system
8. Easy and low maintenance
9. closed system for clean machine environment
10. Various modification choices e.g. angle of inclination, machine speed and screen plates
11. Low consumption of energy & self-cleaning brushes
12. Maintenance openings supported by gas springs allow convenient accessibility.
Separates Waste Into 3 Fractions
These machines can be used in both big and small plants based on the waste quantity and segregation capacity of the machines as they come in different variants and are highly adjustable and simple to install.

Ballistic Separator Waste Segregation Capacity: 10 TPH – 30 TPH

Waste Segregation Machine

Our Services

Most Common Advantages of Using Waste Segregation Machine

The customizable nature of the Movable Ballistic Separator caters to modern client demands and presents a multitude of advantages:

Fast and enormous production diligently

  • Efficiently handles fast and substantial production volumes
  • Minimizes wear and tear, ensuring longevity
  • User-friendly and easily manageable
  • Low power consumption for cost-effectiveness is one of the major specifications
  • Requires minimal human intervention
  • Consistently maintains high uptimes
  • Addresses a spectrum of customer challenges, from simple to complex
  • Inherently versatile in its applications
  • Reduces both operational and maintenance costs is the working principle of ballistic         separator
  • Offers flexibility with minimal shifting time

The working principle of the Ballistic Separator remains highly effective regardless of the size or shape of materials, showcasing remarkable capability in effortlessly handling multiple sorting operations.

Most Common Advantages of Using Waste Segregation Machine

Alwazo solution’s ballistic separator stands as the optimal choice for cost-effective and readily available solutions, ensuring efficient sorting operations.

Specifically designed to segregate biodegradable and non-biodegradable waste solids, our ballistic separators offer versatility. With adjustable rotational and conveying speeds, these separators allow modification of ballistic separation and material mixing levels.

Achieving a separation accuracy of up to 90%, our machines are powered by an electrical gear motor, establishing us as one of the most reliable ballistic separator manufacturers in India.

Explore the significance of ballistic separators in waste management with us—an aspect you simply can’t overlook.

Efficient Sorting Operation:

The Ballistic Separator Machine is the high load segregation device that segregates waste of different types based on their size and weight,

Such as:
  • Construction & Demolition Waste (C&D)
  • Stones
  • Fibers
  • Wood
  • Glass
  • Metal
  • Rubber
  • Plastic
  • Paper
  • Containers
  • Cans
  • Cardboards
  • Other recycling products
